Analyzer Bore Surface Defect Inspection
| Sl.No | Characteristics | Specification |
|---|---|---|
| 1. | Light source | Laser |
| 2. | Wavelength | 670nm |
| 3. | Minimum Inspection diameter | Ø4mm |
| 4. | Maximum rpm | 18,000 rpm |
| 5. | Positioning Accuracy | 0.01mm |
| 6. | Maximum Inspection length | 200mm |
| 7. | Minimum Defect detectable size | 0.2mm |
| 8. | Pixel resolution | 0.01mm |
| 9. | Maximum Sampling Frequency | 2.4mHZ |
| 10. | Probe Model | SG – LSDC |
